OptiDoors
1 / 5
| Category | Specifications & Options |
|---|---|
| Profiles |
• 6063-T5 high quality thermal break aluminum profiles • 6063-T5 high quality non-thermal break aluminum profiles • PVC/UPVC profiles |
| Glass |
• Double tempered glazing: 5+12A+5mm; 6+12A+6mm; etc. • Single tempered glazing: 6mm; 8mm; 10mm; 12mm; etc. • Laminated glazing: 8.76mm; 10.76mm; etc. |
| Hardware | German brand, Australian brand, or top Chinese brand |
| Mesh Options | Stainless steel security mesh, Aluminum security mesh, Fiberglass flyscreen, Retractable flyscreen |
| Surface Treatment | Powder coating, Anodized, Electrophoresis, Wood Grain finish |
SP86, SP100, SP130, SP150 series available for residential, commercial, and luxury villa applications.
Grill options and heavy-duty security mesh available.
Flyscreen designed for easy removal and maintenance cleaning.
Includes timber reveal structure for streamlined installation.
Fin flat angle engineered specifically for double brick building systems.
High-security stainless steel mesh and bushfire-rated aluminum netting.
Double chain system for heavy duty operation; auto controllers for high-position installations.
Glass accommodates thicknesses up to 6.38mm - 19mm, certified for sound insulation (up to STC 39) and energy ratings.
Standard sizes serve as a general baseline, with custom dimensions fully supported upon request. Windows and doors vary across every architectural project, and manufacturing can be tailored to meet your exact structural and aesthetic specifications.
Approved by Australian Window Association, SAI Global, and TUV.
Fabricated in strict accordance with AS2047 and AS2208 / ANSIZ97.1 glass standards.
Fully compliant with North American CSA, NFRC, and Florida Miami-Dade testing requirements.
Corners wrapped with thick corrugated board and secured with protective film layer.
Loaded onto 2.0T capacity steel pallets carrying approximately 10-15 door/window units.
Secured with steel bars and screws to ensure stability, wrapped entirely to block moisture and dust.
Forklift container loading with protective air bags inserted for 100% safe transit during shipping.
Complete window and door systems are supplied, including profiles, hardware, accessories, glass units, as well as fully assembled products ready for job site installation.
To provide an exact quote, please submit: 1) Shop drawings/schedule showing dimensions, quantity, and opening types; 2) Preferred frame color; 3) Glass type, thickness (single, double, or laminated), and performance coatings (Low-E, Tinted, etc.).
All products are custom-manufactured to match the specific dimensions and architectural requirements of your project.
Standard production delivery takes approximately 38 days following deposit confirmation and approved shop drawings. Standard payment terms require a 30%-50% deposit via T/T, with the balance due prior to shipment. Irrevocable L/C at sight is also accepted.
Glass is pre-installed at the factory based on unit dimensions to ensure safety during transit and ease of site installation. Onsite glazing is recommended primarily for oversized units.
A 10-year quality warranty is provided covering frame integrity, color retention, and smooth operation of all hardware elements under standard operating conditions.
