Aluminum Patio Door is loved and praised by many families. It provides not only convenient switching, but also effectively decorates the home, creating a warm, inviting atmosphere and bringing people closer together.
When closed, this aluminum patio door allows abundant natural light into your house with easy accessibility through a smooth single operating sliding mechanism.
| Category | Item | Specification Details |
|---|---|---|
| Aluminium Profiles | Aluminium Alloy | 6063-T5 |
| Wall Thickness | 1.2mm – 2.0mm (Normally 1.4mm for windows, 2.0mm for doors) | |
| Surface Finishing & Color |
• Anodized (Silver & Bronze) • Powder Coating (Color confirmed with buyer) • Electrophoresis (Silver & Champagne) • PVDF |
|
| Thermal Break System | Designed with thermal break aluminium system for enhanced energy saving performance. | |
| Glass Options | Glass Type | Float glass, Insulated double glass, Insulated triple glass, Reflective glass, Low-E glass, Tempered glass, Laminated glass, Customized art glass |
| Glass Thickness | Single: 4mm - 12mm, Double Glazing | |
| Glass Color | Clear, Super Clear, Tinted Blue, Green, Coffee Brown, Grey, etc. | |
| Hardware | Brand & Quality | High quality hardware, made in China of well-known brand. |
| Production Standard | Compliance | Based on shop drawings approved by the buyer (e.g., AS2047 Standard). |
Our patio doors are engineered and manufactured based on approved shop drawings and built to meet standards such as the Australia AS2047 standard for structural performance and weather resistance.
The profile wall thickness ranges between 1.2mm and 2.0mm using 6063-T5 aluminum alloy. Typically, 1.4mm thickness is used for windows and 2.0mm for high-durability doors.
Yes, our aluminum patio doors utilize a thermal break profile system, which significantly reduces heat transfer and provides superior energy-saving functions for your home.
We offer a wide selection of glass types including float, insulated double/triple, Low-E, tempered, laminated, and custom art glass. Glass thickness ranges from 4mm to 12mm for single glazing, as well as double glazing in clear, super clear, or tinted blue, green, coffee brown, and grey shades.
Finishing options include Anodized (Silver & Bronze), Powder Coating (customized colors), Electrophoresis (Silver & Champagne), and high-durability PVDF coatings.
We equip our doors with high-quality, durable hardware components manufactured by well-known brands to ensure long-lasting performance and smooth operation.
